Advantech-DLoG DLT-V72 Series Manual V2.00 57 / 94
11. Technical data
11.1. General
CPU, chipset, RAM, BIOS, CFast, SSD
CPU
Chipset
Cache
Intel
ATOM™ E3845 Quad Core 1.91 GHz
Dual channel 1333 MHz memory bus speed
2 MB L2 cache, 22 nm
RAM 4 GB RAM
DDR3L Technology
BIOS AMI Aptio UEFI; ACPI 5.0 compliant
Real-time clock Real-time clock with a power reserve of up to 5 years
CFast 4 GB and more CFast memory card
Housing, material, weight
Weight
Respectively with CFast, mounted cable cover, strain relief rail and low profile antenna with
Summit card:
DLT-V7210P Approx. 3.65 kg
DLT-V7210K Approx. 3.70 kg
DLT-V7212P Approx. 4.65 kg
Battery pack Approx. 0.15 kg
Material Rugged aluminum-cast housing
ESD safe
Display and touchscreen
DLT-V7210 10,4“ XGA 1024 x 768
400 cd/m²
Manually adjustable Brightness control
DLT-V7210K 10.1“ WXGA 1280 x 800
500 cd/m²
Manually adjustable Brightness control
DLT-V7212 12,1“ XGA 1024 x 768
500 cd/m²
Manually adjustable Brightness control
The LCD display of the DLT-V72 series fulfills the highest quality standards and was inspected for pixel
defects. However, due to technological reasons pixel defects can occur.
This is not a malfunction; it is a part of the technical specifications.
