Advantech-DLoG DLT-V72 Series Manual V2.00 59 / 94
Graphic, touch and network controller
VGA controller Intel
HD Graphics DX11
OpenGL 3.2
Full HW Acceleration for decode/encode of MPEG2 and H.264
Shared memory architecture
Up to 24 bit color depth, depending on which LCD is used
Resistive touch
controller
12-bit touch controller for touchscreens with USB interface
PCT touch controller DLT-V7210:
X21-Y28 channel PCT controller with USB interface and Advantech-
DLoG-specific firmware
DLT-V7212:
X52-Y40 channel PCT controller with USB interface and Advantech-
DLoG-specific firmware
Network controller Intel
®
I210 Gigabit Ethernet 10/100/1000 MB/s
Network connection RJ45 connector
Integrated carrier
Two integrated status LEDs
Internal speaker, sound
The DLT-V72 is equipped with an internal speaker as standard (2 W).
The system messages from the industrial PC are output via this speaker.
The internal speaker is configured in the audio settings for the operating system in question.
