AMT-70/AMT-73/AMT-75 Installation and Operation
Figure 60: Redundancy Connections: ASI interface as Data Input
oftware Configuration
Skip to section 11.2 S
.
123
Shelf A
Shelf B
RF OUT
DATA IN
P4
P7 (ASI)
J5 (OUT)
SPLITTER
(IN)
SWITCH
(OUT)
RACK-MOUNT
BRACKET
