AMT-70/AMT-73/AMT-75 Installation and Operation
11.1.2 RS-530 / HSSI interface
• 1U rack mounted redunancy shelf (see below for appropriate Part Number)
• BNC interface (Kit P/N 19A-250000-000)
• Redunancy shelf with TNC I/O (P/N 16A-250000-100)
For the F / N variant, the following are supplied:
• 2 x F-Male to F-Male cables (P/N 26A-100809-K01)
Your redundancy kit may also include optional extras:
The core redundancy hardware kit consists of the following:
• 2 x 15-Pin D-Sub M-M redundancy signalling cables (P/N 26A-400805-D01)
• 2 x AC Power Supply cables with North American plugs (P/N 670-000380-001)
• 2 x 25-Pin D-Sub M-M cables for RS-530 interface (P/N 26A-400805-E01)
i.e. the above section inventory is common to ALL 1:1 RS-530/HSSI kits.
The redundancy chassis comes with your choice of RF interface, one of 3 variants:
• TNC interface (Kit P/N 19A-250000-100)
• F in / N out interface (Kit P/N 19A-250000-200)
For the BNC variant, the following are supplied:
• Core redundancy kit, as described at the top
• Redundancy shelf with BNC I/O (P/N 16A-250000-000)
• 4 x BNC-M to BNC-M cables (P/N 26A-100809-I01)
For the TNC variant, the following are supplied:
• Core redundancy kit, as described at the top
• 4 x TNC-M to TNC-M cables (P/N 26A-100809-L01)
• Core redundancy kit, as described at the top
• Redunancy shelf with F-type In / N-type Out (P/N 16A-250000-200)
• 2 x N-Male to N-Male cables (P/N 26A-100809-M01)
• 2 x SCSI-II M-M cables (HSSI operation) (P/N 670-00HSSI-002)
The three chassis should be placed into a rack mount. The 1:1 Redundancy unit is optimally placed
beneath the two AMT-70 chassis to be connected. A connection overview is illustrated in
Figure 61.
124
