AMT-70/AMT-73/AMT-75 Installation and Operation
NETWORK Menu 3
NETWORK Menu 4
4.2.5.5.5 The CONTROL/PORTS/RS485 option
The RS485 menu provides the means to setup the address of the modem’s RS-485 M&C port, plus
provides a means for setting the type of communication (packet or command mode), the baud rate, the
parity, the number of data bits, and the number of stop bits for the asynchronous data port. More
information about the two methods of communication is provided in subsequent sections of this
manual.
RS485 Menu 2
77
P R I M G A T E
W
A Y = 1 9 2. 168. 254. 238
S C N D A D D R = 1 9 2 . 1 6 8 . 2 5 4 . 2 3 7
M A S K = 2 5 5 . 2 5 5 . 2 5 5 . 0 0 0
S C N D G A T E
W
A Y = 1 9 2. 168. 254. 237
R S 4 8 5 A D R S = 0 0 5 D e c
(Addresses from 1-15)
C O N T R O L = n one
p acket
c ommand
R S 4 8 5 S P E E D = 0 0 4 8 0 0 P A R I T Y = N O N E
0 0 9 600 E EV N
0 0 1 9 20 ODD
0 3 8 400
0 7 5 200
1 1 5 200
D A T A B I T S = 8 STOPBI TS=1
2 7
