Advantech AMT-73 - Chapter 14 APPENDIX C EMBEDDED ROUTER

AMT-70/AMT-73/AMT-75 Installation and Operation
CHAPTER 14 APPENDIX C EMBEDDED
ROUTER
AMT70/73 modems can be optionally equipped with the Advantech Embedded Router module (AERo)
that provides the AMT70/73 modems with the full functionality of an IP router, FRAD (Frame Relay
Access Device) and bridge. With this option the AMT70/73 modems, without the need for any
additional data telecommunication equipment, can support a wide range of network solutions.
AMT70
Mod
DCE
RS-530
TX
RFFE Out
AMT70
dDemo
DCE
RS-530
RX
RFFE In
DTE
RS-530
TX
DTE
RS-530
RX
DTE
RS-530
TX
DTE
RS-530
RX
AERo
Advantech Embedded Router
RS-232
sole
10/100B-T
Con
Serial 0 Serial 1
Figure 73: Embedded Router Support
ds two additional RJ-45 connectors (JA and JB) to the rear panel – Figure 2.
Connector JA provides a standard 10/100B-T data c control
on e
The AERo option ad
onnection and JB a RS-232, Cisco like,
sol port. c
AMT-70/73L Rear Panel equipped with AERo option
144
Figure 74:
