AMT-70/AMT-73/AMT-75 Installation and Operation
(dB) (dB) Viterbi 1/2 Viterbi 2/3 Viterbi 3/4 Viterbi 7/8 TPC16K-2/5 TPC16K-3/5 TPC4K-3/4 TPC16K-8/9 TPC16K-19/20
(S
+
N)/N
E
s
/N0
Eb/N0
Eb/N0
Eb/N0
Eb/N0
Eb/N0
Eb/N0
Eb/N0
Eb/N0
Eb/N0
4.0 1.8 -1.2 -2.5 -3.0 -3.6 -0.7 -1.9 -3.1 -3.6 -3.8
4.5 2.6 -0.4 -1.7 -2.2 -2.8 0.1 -1.1 -2.3 -2.8 -3.0
5.0 3.3 0.3 -0.9 -1.4 -2.1 0.8 -0.4 -1.5 -2.0 -2.3
5.5 4.1 1.1 -0.2 -0.7 -1.4 1.5 0.3 -0.8 -1.3 -1.6
6.0 4.7 1.7 0.5 0.0 -0.7 2.2 1.0 -0.1 -0.6 -0.9
6.5 5.4 2.4 1.1 0.6 0.0 2.9 1.7 0.5 0.0 -0.2
7.06.03.01.81.30.63.52.31.20.70.4
7.56.63.62.41.91.24.12.91.81.31.0
8.07.34.23.02.51.84.73.52.41.91.6
8.57.84.83.63.12.45.34.13.02.52.2
9.08.45.44.23.63.05.94.73.63.02.8
9.59.06.04.74.23.56.45.34.13.63.4
10.0 9.5 6.5 5.3 4.8 4.1 7.0 5.8 4.7 4.2 3.9
10.5 10.1 7.1 5.8 5.3 4.7 7.6 6.4 5.2 4.7 4.5
11.0 10.6 7.6 6.4 5.9 5.2 8.1 6.9 5.8 5.3 5.0
11.5 11.2 8.2 6.9 6.4 5.7 8.6 7.5 6.3 5.8 5.6
12.0 11.7 8.7 7.5 6.9 6.3 9.2 8.0 6.9 6.3 6.1
12.5 12.2 9.2 8.0 7.5 6.8 9.7 8.5 7.4 6.9 6.6
13.0 12.8 9.8 8.5 8.0 7.3 10.2 9.1 7.9 7.4 7.1
13.5 13.3 10.3 9.0 8.5 7.9 10.8 9.6 8.4 7.9 7.7
14.0 13.8 10.8 9.6 9.1 8.4 11.3 10.1 9.0 8.4 8.2
14.5 14.3 11.3 10.1 9.6 8.9 11.8 10.6 9.5 9.0 8.7
15.0 14.9 11.9 10.6 10.1 9.4 12.3 11.1 10.0 9.5 9.2
15.5 15.4 12.4 11.1 10.6 9.9 12.8 11.7 10.5 10.0 9.7
16.0 15.9 12.9 11.6 11.1 10.4 13.4 12.2 11.0 10.5 10.3
16.5 16.4 13.4 12.1 11.6 11.0 13.9 12.7 11.5 11.0 10.8
17.0 16.9 13.9 12.7 12.1 11.5 14.4 13.2 12.1 11.5 11.3
17.5 17.4 14.4 13.2 12.7 12.0 14.9 13.7 12.6 12.0 11.8
18.0 17.9 14.9 13.7 13.2 12.5 15.4 14.2 13.1 12.6 12.3
18.5 18.4 15.4 14.2 13.7 13.0 15.9 14.7 13.6 13.1 12.8
19.0 18.9 15.9 14.7 14.2 13.5 16.4 15.2 14.1 13.6 13.3
19.5 19.5 16.4 15.2 14.7 14.0 16.9 15.7 14.6 14.1 13.8
20.0 20.0 16.9 15.7 15.2 14.5 17.4 16.2 15.1 14.6 14.3
20.5 20.5 17.5 16.2 15.7 15.0 17.9 16.7 15.6 15.1 14.8
21.0 21.0 18.0 16.7 16.2 15.5 18.4 17.2 16.1 15.6 15.3
21.5 21.5 18.5 17.2 16.7 16.0 18.9 17.8 16.6 16.1 15.8
22.0 22.0 19.0 17.7 17.2 16.5 19.4 18.3 17.1 16.6 16.3
22.5 22.5 19.5 18.2 17.7 17.0 19.9 18.8 17.6 17.1 16.8
23.0 23.0 20.0 18.7 18.2 17.5 20.4 19.3 18.1 17.6 17.3
23.5 23.5 20.5 19.2 18.7 18.0 20.9 19.8 18.6 18.1 17.9
24.0 24.0 21.0 19.7 19.2 18.5 21.4 20.3 19.1 18.6 18.4
24.5 24.5 21.5 20.2 19.7 19.0 21.9 20.8 19.6 19.1 18.9
25
.
0
25
.
0
22
.
0
20
.
7
20
.
2
19
.
5
22
.
5
21
.
3
20
.
1
19
.
6
19
.
4
Figure 72: 16QAM (S+N)/N Conversion Chart
