Advantech AMT-73 User Manual

AMT-70/AMT-73/AMT-75 Installation and Operation
(dB) (dB) Viterbi 1/2 Viterbi 2/3 Viterbi 3/4 Viterbi 7/8 TPC16K-2/5 TPC16K-3/5 TPC4K-3/4 TPC16K-8/9 TPC16K-19/20
(S+N)/N Es/N0 Eb/N0 Eb/N0 Eb/N0 Eb/N0 Eb/N0 Eb/N0 Eb/N0 Eb/N0 Eb/N0
4.0 1.8 1.8 0.5 0.0 -0.6 2.3 1.1 -0.1 -0.6 -0.8
4.52.62.61.30.80.23.11.90.70.20.0
5.03.33.32.11.60.93.82.61.51.00.7
5.54.14.12.82.31.64.53.42.21.71.4
6.04.74.73.53.02.35.24.02.92.42.1
6.55.45.44.13.63.05.94.73.53.02.8
7.06.06.04.84.33.66.55.34.23.73.4
7.56.66.65.44.94.27.15.94.84.34.0
8.07.37.36.05.54.87.76.55.44.94.6
8.57.87.86.66.15.48.37.16.05.55.2
9.08.48.47.26.76.08.97.76.66.05.8
9.59.09.07.77.26.69.58.37.16.66.4
10.0 9.5 9.5 8.3 7.8 7.1 10.0 8.8 7.7 7.2 6.9
10.5 10.1 10.1 8.8 8.3 7.7 10.6 9.4 8.2 7.7 7.5
11.0 10.6 10.6 9.4 8.9 8.2 11.1 9.9 8.8 8.3 8.0
11.5 11.2 11.2 9.9 9.4 8.8 11.7 10.5 9.3 8.8 8.6
12.0 11.7 11.7 10.5 10.0 9.3 12.2 11.0 9.9 9.3 9.1
12.5 12.2 12.2 11.0 10.5 9.8 12.7 11.5 10.4 9.9 9.6
13.0 12.8 12.8 11.5 11.0 10.3 13.3 12.1 10.9 10.4 10.2
13.5 13.3 13.3 12.1 11.5 10.9 13.8 12.6 11.5 10.9 10.7
14.0 13.8 13.8 12.6 12.1 11.4 14.3 13.1 12.0 11.5 11.2
14.5 14.3 14.3 13.1 12.6 11.9 14.8 13.6 12.5 12.0 11.7
15.0 14.9 14.9 13.6 13.1 12.4 15.3 14.2 13.0 12.5 12.2
15.5 15.4 15.4 14.1 13.6 12.9 15.9 14.7 13.5 13.0 12.8
16.0 15.9 15.9 14.6 14.1 13.5 16.4 15.2 14.0 13.5 13.3
16.5 16.4 16.4 15.2 14.6 14.0 16.9 15.7 14.6 14.0 13.8
17.0 16.9 16.9 15.7 15.2 14.5 17.4 16.2 15.1 14.5 14.3
17.5 17.4 17.4 16.2 15.7 15.0 17.9 16.7 15.6 15.1 14.8
18.0 17.9 17.9 16.7 16.2 15.5 18.4 17.2 16.1 15.6 15.3
18.5 18.4 18.4 17.2 16.7 16.0 18.9 17.7 16.6 16.1 15.8
19.0 18.9 18.9 17.7 17.2 16.5 19.4 18.2 17.1 16.6 16.3
19.5 19.5 19.5 18.2 17.7 17.0 19.9 18.7 17.6 17.1 16.8
20.0 20.0 20.0 18.7 18.2 17.5 20.4 19.3 18.1 17.6 17.3
20.5 20.5 20.5 19.2 18.7 18.0 20.9 19.8 18.6 18.1 17.8
21.0 21.0 21.0 19.7 19.2 18.5 21.4 20.3 19.1 18.6 18.3
21.5 21.5 21.5 20.2 19.7 19.0 21.9 20.8 19.6 19.1 18.9
22.0 22.0 22.0 20.7 20.2 19.5 22.4 21.3 20.1 19.6 19.4
22.5 22.5 22.5 21.2 20.7 20.0 23.0 21.8 20.6 20.1 19.9
23.0 23.0 23.0 21.7 21.2 20.5 23.5 22.3 21.1 20.6 20.4
23.5 23.5 23.5 22.2 21.7 21.1 24.0 22.8 21.6 21.1 20.9
24.0 24.0 24.0 22.7 22.2 21.6 24.5 23.3 22.1 21.6 21.4
24.5 24.5 24.5 23.2 22.7 22.1 25.0 23.8 22.6 22.1 21.9
25
.
0
25
.
0
25
.
0
23
.
7
23
.
2
22
.
6
25
.
5
24
.
3
23
.
1
22
.
6
22
.
4
141
Figure 70: QSSK (S+N) Conversion Chart
