Benchmark 1500 - 2000 Boilers
APPENDIX A: BOILER MENU DESCRIPTIONS
Page 132 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E
10/01/2015 Ph.: 800-526-0288 GF-142
TABLE A-2: SETUP MENU ITEM DESCRIPTIONS
See section 3-5 for a range of choices and the default values.
SETUP MENU
MENU OPTIONS DESCRIPTION
1 Password
Allows Level 1 or Level 2 password to be entered.
Entering the Level 1 Password (159) allows options in the Setup,
Configuration and Tuning menus to be modified.
Entering the Level 2 Password (6817) allows options in the
Calibration and Diagnostics Menus to be changed or activated, in
addition to all Level 1 Menu options.
2 Language
Permits selection of English, Spanish or French for displayed
messages.
3 Time Displays time from 12:00 am to 11:59 pm.
4 Date Displays dates from 01/01/00 to 12/31/99
5 Unit of Temp
Permits selection of temperature displays in degrees Fahrenheit (°F)
or degrees Celsius (°C).
6 Comm Address
For RS-485 communications (0 to 127). RS232 should have its own
(programmable) password.
7 Baud Rate
Allows communications Baud Rate to be set (2400 to 19.2K).
Default is 9600.
8 OnAER Mode Allows selection of either Ethernet or SD Card
9 Min Upload Timer
Mandatory for AERCO OnAER Remote Data Collection (ORDC).
This parameter enables ORDC and defines the minimum amount of
time between heartbeat data uploads in seconds. The COMM LED
will light during the upload.
10 Unit Alpha
Mandatory for AERCO OnAER Remote Data Collection. This value
must match the first alpha digit on the Code Plate, e.g., G-12-1234.
11 Unit Year
Mandatory for AERCO OnAER Remote Data Collection. This value
must match the 2-digit year on the Code Plate, e.g., G-
-1234.
12 Unit Serial #
Mandatory for AERCO OnAER. Remote Data Collection. This value
must match the 4-digit serial # on the Code Plate, e.g., G-12-1234.
13 Software Version Identifies the current software version of the control box.
