CHAPTER 6 – SAFETY DEVICE TESTING
Page 86 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E
10/01/2015 Ph.: 800-526-0288 GF-142
Figure 6-8: Air/Fuel Valve Purge and Ignition Switch Locations
6.12 SAFETY PRESSURE RELIEF VALVE TEST
Test the safety Pressure Relief Valve in accordance with ASME Boiler and Pressure Vessel
Code, Section VI.
172
171
170
169
Ignition
Position
Switch
Purge
Position
Switch
AIR IN
TO BLOWER
VALVE
POSITION
DIAL
AIR/FUEL VALVE
SWITCH WIRING
BREAKOUT
