Benchmark 1500 - 2000 Boilers
CHAPTER 5 – MODE OF OPERATION
Page 72 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E
10/01/2015 Ph.: 800-526-0288 GF-142
5.7.1 Combination Control System Field Wiring
Wiring for this system is between the ACS, the ACS Relay Box, and the terminals in the I/O
Box. Wire the units using a shielded twisted pair of 18 to 22 AWG wire. When wiring multiple
units, each unit’s wiring must conform to the above.
5.7.2 Combination Control System Setup and Startup
Setup for the COMBINATION mode requires entries to be made in the Configuration menu for
boiler mode, remote signal type and setpoint. The setpoint is adjustable from 40°F to 190°F
(4.4°C to 87.8°C).
Enter the following settings in the Configuration menu:
Table 5-5: Combination Mode Settings
Menu Option Setting
Boiler Mode Combination
Remote Signal Network
Internal Setpt 40°F to 190°F (4.4°C to 87.8°C)
Refer to section 3.3 for instructions on changing menu options.
While it is possible to change other temperature-related functions for COMBINATION mode,
these functions are preset to their factory default values. These default settings work well in
most applications. It is suggested that AERCO be contacted prior to changing settings other
than the unit’s setpoint. For a complete listing of temperature related function defaults, see
Chapter 3.
To set the unit to the MANUAL mode, press the AUTO/MAN switch. The MANUAL LED will
light.
To set the unit back to the AUTO mode, press the AUTO/MAN switch. The MANUAL LED will
go off and the REMOTE LED will light.
When the boiler is switched to ACS control, the ACS controls the valve position. There are no
setup requirements to the boiler(s) in this mode.
