Benchmark 1500 - 2000 Boilers
CHAPTER 3 – OPERATION
Page 42 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E
10/01/2015 Ph.: 800-526-0288 GF-142
3.5 SETUP MENU
The Setup menu (Table 3-3) permits the operator to enter the unit password (159) which is
required to change the menu options. To prevent unauthorized use, the password will time-out
after 1 hour. Therefore, the correct password must be reentered when required. In addition to
permitting password entries, the Setup menu is also used to enter date and time, and units of
temperature measurements. A view-only software version display is also provided to indicate
the current Control Box software version.
Table 3-3: Setup Menu
Menu Item Display
Available Choices or Limits
Default
Minimum Maximum
1
Password 0 9999 0
2
Language English English
3
Time 12:00 am 11:59 pm
4
Date 01/01/00 12/31/99
5
Unit of Temp Fahrenheit or Celsius Fahrenheit
6
Comm Address 0 127 0
7
Baud Rate 2400, 4800, 9600, 19.2K 9600
13
Software Ver 0.00 Ver 9.99 Current software version
3.6 CONFIGURATION MENU
The Configuration menu shown in Table 3-4 permits adjustment of the Internal Setpoint (Setpt)
temperature regardless of whether the valid password has been entered. Setpt is required for
operation in the CONSTANT SETPOINT mode. The remaining options in this menu require the
valid password to be entered, prior to changing existing entries. This menu contains a number
of other configuration settings which may or may not be displayed, depending on the current
operating mode setting.
NOTE
The Configuration menu settings shown in Table 3-4 are Factory-
Set in accordance with the requirements specified for each
individual order. Therefore, under normal operating conditions, no
changes will be required.
