Benchmark 1500 - 2000 Boilers
CHAPTER 3 – OPERATION
Page 46 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E
10/01/2015 Ph.: 800-526-0288 GF-142
3.9 BST (Boiler Sequencing Technology) Menu
The BST menu must be enabled in order to be displayed and accessed. The BST Menu item,
located at the end of the Configuration menu (item 32 in Table 3-4), must be se to Enabled.
The BST menu contains all of the items required to configure, operate and monitor the
functionality of the BST System. There are over 50 items in this menu, and selecting any
particular item from the list, for inspection or modification, could be time consuming. As a result,
the BST menu has been segmented into FIVE logical groups based on functionality.
The five Item groups are:
1. BST Monitor Items
2. *BST SETUP MENU*
3. *OPERATE MENU*
4. *TEMP CTRL MENU*
5. *BST COMM MENU*
These displayed item groups are displayed in UPPER CASE letters, and are bounded by an
asterisk * in order to readily identify them within the item list.
The Items contained in group 1 (BST Monitor Items) are always displayed within the menu, as
these items are critical for proper system operation. Therefore, the BST Monitor Items Header
itself is not displayed.
The Items contained in groups 2-5 are not displayed unless that particular item group has been
enabled from the C-More keypad.
Menu Item Display
Available Choices or Limits
Default
Off BST Slave BST Master Off
2 BST Setpoint BST Setpt Lo Limit BST Setpt Hi Limit 130°F (54.4°C)
3 Header Temp Read Only – current Header temperature in °F N/A
4 BST Fire Rate 0 100% Fire rate %
5 BST Ave Fire Rate 0 100% Avg Fire Rate %
6 BST Outdoor Temp Read Only – current outdoor temperature in °F N/A
7 Units Available 0 8 Units Present
8 Units Ignited 0 8 Units firing
9 BST Valve State 0 (CLOSED) 1 (OPEN) 0
10 1 Comm Errors 8 0 9 0
11 1 BST Units 8 0 (see table) 0 (see table) 0
13 BST Setpoint Mode Constant Setpoint
Constant Setpt
14 Head Temp Source Network FFWD Temp FFWD Temp
15 Header Temp Addr 0 255 240
16 Header Temp Point 0 255 14
17 BST Outdoor Sens Disabled Enabled Disabled
