Aerco Benchmark 2000 User Manual

Benchmark 1500 - 2000 Boilers
APPENDIX G – PART LIST DRAWINGS
Page 154 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E
10/01/2015 Ph.: 800-526-0288 GF-142
TABLE A – Benchmark 1500
TABLE A – Benchmark 2000
Part No.
Description
Item 88
Item 87
Part No.
Description
Item 88
Item 87
58088-C30 30 PSI (207 kPa) KIT (CONBRACO) 92015-17 123675-5 58087-1 30 PSI (207 kPa) 123661 123675-5
58088-C50 50 PSI (345 kPa) KIT (CONBRACO) 92015-18 123675-5 58087-2 50 PSI (345 kPa) 124283 123675-5
58088-C60 60 PSI (414 kPa) KIT (CONBRACO) 92015-19 123675-6 58087-3 75 PSI (517 kPa) 5130-75 123675-6
58088-C75 75 PSI (517 kPa) KIT (CONBRACO) 92015-20 123675-6 58087-4 100 PSI (689 kPa) 5130-100 123675-6
58088-C100 100 PSI (689 kPa) KIT (CONBRACO) 92015-21 123675-6 58087-5 150 PSI (1034 kPa) 123659 123675-7
58088-C125 125 PSI (862 kPa) KIT (CONBRACO) 92015-22 123675-6 58087-6 60 PSI (414 kPa) 92022 123675-6
58088-C150 150 PSI (1034 kPa) KIT (CONBRACO) 92015-6 123675-7 58087-7 125 PSI (862 kPa) 5130-125 123675-6
58088-W30 30 PSI (207 kPa) KIT (WATTS) 92015-11 123675-5 58087-8 160 PSI (1103 kPa) 92015-23 123675-7
58088-W50 50 PSI (345 kPa) KIT (WATTS) 92015-12 123675-5
58088-W60 60 PSI (414 kPa) KIT (WATTS) 92015-13 123675-6
58088-W75 75 PSI (517 kPa) KIT (WATTS) 92015-14 123675-6
58088-W100 100 PSI (689 kPa) KIT (WATTS) 92015-15 123675-6
58088-W125 125 PSI (862 kPa) KIT (WATTS) 92015-16 123675-6
58088-W150 150 PSI (1034 kPa) KIT (WATTS) 5130-150 123675-7
58088-W160 160 PSI (1103 kPa) KIT (KUNKLE) 92015-23 123675-7
Benchmark 1500 - 2000 Part List – Continued
Item #
Qty
Part #
Description
Item #
Qty
Part #
Description
SHEET METAL/PANEL ASSEMBLY
OTHER ACCESSORIES & PARTS
72
1
37117
BACK PANEL, RIGHT
87 
1
SEE
TABLE A
PRESSURE/TEMP GAUGE
73 
1
37118
BACK PANEL, LEFT
88 
1
SEE
TABLE A
PRESSSURE RELIEF VALVE
74
2
35029
TOP RAIL
89 
1
123540
EXTERNAL MANUAL SHUT-OFF VALVE
75
1
25078
ASSEMBLY: FRONT PANEL
90
1
69126
LOW WATER CUTOFF/CAPACITOR ASSY
76
1
25072
FRONT PANEL ASSY
91
1
123863
1/8" NTP BALL VALVE
77
1
72068
DOME LABEL
92
1
92094
3/4" DRAIN VALVE
78
2
59179
HANDLE, CONCEALED
93 
1
59043
CONDENSATE FLOAT
79
4
59133
LATCH
94 
1
24441
COND. TRAP ASSY
80
1
37119
FRONT TOP PANEL
95
1
59178
1/8" AIR VENT
81
1
37120
BACK TOP PANEL
96
1
90052
NIPPLE 1/8" X 1.5” (3.8 mm) LG
82
2
30117
SIDE PANEL
83
1
74031
BMK 1500 LOGO
1
74033
BMK 2000 LOGO
100 
1
92084-6
MOTORIZED SEQUENCING ISOLATION
VALVE (OPTIONAL)
84
1
39164
8" AIR INLET ADAPTER, BMK2000
1
39200
6" AIR INLET ADAPTER, BMK1500
 Not shown on drawing
AERCO
International, Inc.
Blauvelt, NY 10913
Benchmark 1500-2000 Part List
01/15/2015
Whole Boiler 29313-1 – 29337-1
Sheet 2 of 7
