Benchmark 1500 - 2000 Boilers
APPENDIX G – PART LIST DRAWINGS
Page 160 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E
10/01/2015 Ph.: 800-526-0288 GF-142
Benchmark 1500-2000 Natural Gas Standard Gas Train – 22188 rev E
Item
Qty
Part #
Description
Item
Qty
Part #
Description
1
1
123542
FLANGE 2" 125# 2"NPT
11
1
97087-20
FLEX HOSE, 20" (50.8 cm) LG
4
1
69005
ACTUATOR, SSOV W/ REGULATOR
14
1
61002-11
LOW GAS PRESSURE SWITCH 3.6" W.C.
(897 Pa)
5
2
12951-2
BUSHING, CONTROL BOX
23
1
124150
VALVE, SSOV 1-1/2" NPT
6
3
92077
1/4" NPT MXF BRASS BALL VALVE
26
1
93382
2'' NPT CAP
7
4
9-22
PIPE PLUG, 1/4" NPT, STEEL
28
1
92006-7
VALVE, BALL BRASS 1-1/2" NPT
8
1
99017
SNUBBER, PRESSURE, 1/4"
29
1
9-294
UNION, 2" NPT 300#
9
1
61002-12
HIGH GAS PRESSURE SWITCH 4.7" W.C.
(1171 Pa)
AERCO
International, Inc.
Blauvelt, NY 10913
Benchmark 1500-2000 Gas Train
05/28/2015
22188 rev E
Sheet 1 of 1
