Benchmark 1500 - 2000 Boilers

CHAPTER 6 – SAFETY DEVICE TESTING

Page 80 of 182 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0097_0E

10/01/2015 Ph.: 800-526-0288 GF-142

Figure 6-3: Bare Boiler – Partial View

BLOWER

HEAT

EXCHANGER

BLOWER

PROOF

SWITCH

AIR/FUEL

VALVE

BLOCKED

INLET

SWITCH

AIR

FILTER

SSOV

IGNITER/INJECTOR

ASSEMBLY

BLOWER

PLENUM

GAS

INLET

MANUAL

SHUT-OFF

VALVE

GAS

TRAIN

A/F VALVE

PLENUM
