Laying Cables and Connecting Wires
Chapter
6
Afimilk MPC Main
Cable Wire Color
Connected to Wire Function Device Wire Color
Blue Body Cable Operating electrode Blue
Yellow Body Cable Holding electrode Yellow
Brown Body Cable Common electrode Brown
Orange Body Cable Thermistor Orange
Light Green Body Cable Thermistor Light Green
White/Pink Pulsator Pulsator Front Blue (per Cable)
White/Green Pulsator Pulsator Rear Brown (per Cable)
Red/Blue Pulsator Pulsator Common (+VBR) Yellow/Green
White Removal Signal DC Removal output (-) Brown (per Cable)
Red/Blue(Jumper)
Removal+Vacuum
Common
Solenoids DC Common
(+VBR)
Blue (per Cable)
Gray/Pink Vacuum Valve DC Vacuum Valve (-) Brown (per Cable)
Red Power Supply 24Vac (0) Blue (per Cable)
Green Power Supply 24Vac (Phase) Brown (per Cable)
Pink Body Solenoid Body Solenoid (H) Red
Purple Body Solenoid Body Solenoid (L) Black
Gray
External Start
Button
External Start Button
Contact
Blue (per Cable
used)
Black
External Start
Button
External Start Button
Contact
Black (Per Cable
used)
White/Brown Additional Input Swing Over Arm Blue (per Cable)
White/Red Communication Communication Signal Pink (Per cable)
White/Blue Communication Communication Signal Black (Per Cable)
Black/Blue Communication Comm. Cable Shield Blue (per Cable)
Black/Yellow
Peripheral
Communication*
Optional- MPC Extender
or AfiLab
White/Yellow
Peripheral
Communication*
Optional- MPC Extender
or AfiLab
