AfiMilk MPC 3 - External Start Button; Hardware and Electronic Configuration

AfiMilk MPC Installation Manual 82
Chapter
8
Unique Setup & Configurations
most cows are assigned with stimulation) OR "double start" (only selected cows
requiring stimulated by the machine).
External Start Button
An external start button may be installed to allow easier operation of milking.
External start functionality is activating milking (start) and de-activating milking (stop if in
milking process). External start may be deactivated for cows with specific codes defined
as security codes (refer to security levels operation chapter for more information).
Hardware and Electronic Configuration
Connect the contact of the external start button as shown in the connection diagram below.
External start buttons may be applied – no need for any specific settings.
