Agilent Technologies 54830 Series Service Guide

Chapter 1: General Information
Specifications & characteristics
1–10
Horizontal
Analog Trigger
dc Gain Accuracy
*2
± 1.25% of full scale at full-resolution channel scale. The dc gain accuracy
decreases 0.08% of full scale per degree C from the firmware calibration
temperature.
Offset Accuracy*
2
± (1.25% of channel offset + 2% of full scale) at full-resolution channel scale.
dc Voltage Measurement
Accuracy*
2,3
Dual Markers ±[(dc gain accuracy)+(resolution)]
Single Marker ±[(dc gain accuracy)
+(offset accuracy)+(resolution/2)]
Bandwidth Limit Filter 20 MHz
AutoProbe Interface AutoProbe is an intelligent communication and power link between compatible
probes and Infiniium scopes. AutoProbe completely configures the oscilloscope for
the attached probe. For instance, it identifies the probe type and sets up the proper
input impedance, attenuation ratio, probe power and offset range, as needed.
Main Time Base Range 54830/31B/D
54832B/D & 54833A/D
500 ps/div to 20 s/div
200 ps/div to 20 s/div
Horizontal Position Range 0 to ±200s
Delayed Sweep Range 1 ps/div to current main time base setting.
Resolution 4 ps
Timebase Accuracy 15 ppm (±0.0015%)
Jitter, rms 8 ps ±0.05ppm x [Delay Time]
Sensitivity*
2
Internal (normal)
For vertical ranges >5 mV/div
dc to 500 MHz: 0.6 div
500 MHz to 1 GHz (50 Ω) 1.5 div
External (54830B/D & 54833A/D) dc to 100 MHz: 0.05x(signal range)
100 MHz to 500 MHz : 0.10x(signal range)
Auxiliary (54831/32B/D) dc to 500 MHz: 300 mV
pp
Level Range Internal 1 MΩ ±8 div from center screen
50 Ω ±8div from center screen
External (54830B/D & 54833A/D) 1 MΩ ±1 V, ±5 V, and ±25 V
50 Ω ±1 V, ±5 V, and ±8 V
Auxiliary (54831/32B/D) ±5 V
Sweep Modes Auto, triggered, single
Trigger Coupling dc, ac, low frequency reject (50 kHz), high frequency reject (50 kHz).
Trigger Holdoff Range 50 ns to 10 s
Trigger Modes Edge
Line
Glitch Select positive or negative polarity,
width. Triggers on glitches as narrow as
500 ps.
Pattern Select inputs as High, Low or X (don't
care) to create pattern. Triggers on
patterns as narrow as 2.5 ns.
Trigger when pattern is entered, exited,
present > t, present over a range of time.
