Agilent Technologies 55B AA

Overview
42 Agilent 55B AA Spectrometer User’s Guide
Figure 7. Sample compartment with front panel and flame shield removed
Nebulizer block assembly
The nebulizer block connects the following components:
 Nebulizer
 Impact bead
 Liquid trap
 Drain tube
 Spray chamber
Figure 8. Nebulizer block assembly (for products with serial numbers 0110xxxx and later)
Burner
Nebulizer block
Drain outlet
Vapor outlet
Burner adjustment
Thimble
Liquid trap
