Interface
54 Agilent 55B AA Spectrometer User’s Guide
Numeric Keys
Figure 17. Numeric keys
The numeric keypad (0-9 and decimal point) is used to enter field values. A Clear
button (‘Clr’) is also included in this group to delete any values entered.
Cursor keys
Figure 18. Cursor keys
There are four cursor keys: ‘Up’, ‘Down’, ‘Left’, and ‘Right’. They are used to move
around the display. The ‘Enter’ key is used to update the parameter setting with the
new value.
NOTE
If the cursor is moved out of a field without ‘Enter’ being pressed, the field’s
contents returns to its previous value.
‘Enter’ is also used on the ‘Optimization’ page to perform a Rescale command.
Alt key
Figure 19. Alt key
‘Alt’ is used in conjunction with other keys to modify their meaning. Pressing ‘Alt’
alone has no effect.
The table below lists the shortcuts available via the keypad.
