5 General Maintenance

122 5975/5977 Series MSD Operating Manual

Figure 35. The analyzer chamber for the HES MSD

Ceramic source board

Ion source

Thumbscrew

Source heater and

temperature sensor wires

Source radiator

Source finger grip

Thumbscrew
