1Introduction

5975/5977 Series MSD Operating Manual 15

MSD Hardware Description

Figure 1. 5977B Series GC/MSD system, shown with an Agilent 7890B GC

ALS

7890B GC

7890B GC control panel

5977B Series

MSD

MSD power switch

GC power switch

System status LED

Main Page

Hardware User Information4
- 5977B Msd4
- 5975/5977 Series MSD Prior to the 5977B MSD4
