5 General Maintenance

5975/5977 Series MSD Operating Manual 135

To Remove the EI HES filaments

Materials needed

• Gloves, clean, lint-free

• Large (8650-0030)

• Small (8650-0029)

• Cloths, clean (05980-60051)

• T6 Torx driver, (8710-2548)

Procedure

1 Vent the MS. (See “Vent the MSD” on page 104.)

2 Open the analyzer chamber. (See “To Open the Analyzer Chamber” on

page 119.)

3 Remove the ion source and place it on a clean cloth on your work surface.

(See “To Remove the EI HES” on page 121.)





CAUTION

Always wear clean gloves to prevent contamination when working in the

analyzer chamber.

WARNING

The analyzer, GC/MS interface, and other components in the analyzer

chamber operate at very high temperatures. Do not touch any part until you

are sure it is cool.
