4 Operating in EI Mode
84 5975/5977 Series MSD Operating Manual
Operating the 5975/5977 MSD From the
Local Control Panel (LCP)
Agilent 5975 and 5977 MSD models introduced before the 5977B MSD have a
local control panel (LCP). The LCP shows the status of the MSD or initiates a task
on the MSD without using the data acquisition software.
Only certain features are available from the LCP. The data acquisition software is
the full-featured controller for most instrument control operations.
Modes of operation
The LCP has two modes of operation: Status and Menu.
Status mode requires no interaction and simply displays the current status of the
MSD instrument or its various communication connections. If you select [Menu],
then [No/Cancel], you will be returned to the Status mode.
Menu mode allows you to query various aspects of the GC/MSD and to initiate
some actions like running a method or sequence or preparing to vent the system.
To access a particular menu option:
Use one or more of the following keys as appropriate to respond to prompts or
select options:
Press [Menu] until the desired menu appears.
Press [
Item] until the desired menu item appears.
Use [
Up] to increase the displayed value or to scroll up (such as in a message list).
Use [
Down] to decrease the displayed value or to scroll down (such as in a message
list).
