4 Operating in EI Mode

5975/5977 Series MSD Operating Manual 83

6 Confirm that BootP is set to OFF. If your LAN assigns IP addresses using a

BootP server, click ON and skip the next step.

7 To update the MSD IP address, Gateway IPA, and SubNet Mask enter the

new values. Before clicking submit, you can recover the previous settings by

clicking Return to Main Menu and then returning here.

8 Click Submit to upload this net configuration to the MSD.



A dialog opens to confirm that the network configuration process has

started. (See Figure 23.)

9 Click OK to close the dialog and wait for the prompt requesting to Manually

reboot of the MSD/SmartCard to activate the new Settings.

10 Use the MSD on/off switch to reboot the MSD SmartCard.

Figure 23. IP address configuration started message
