5 General Maintenance

5975/5977 Series MSD Operating Manual 161

9 Close the analyzer chamber. (See “To Close the Analyzer Chamber” on

page 162.)

Figure 51. Replacing the EM horn on a Series II Detector

Figure 52. Electron multiplier horn

Retaining clip

Electron multiplier horn

Blue signal wire
