3 Intuvo 9000 GC Column Maintenance
5975/5977 Series MSD Operating Manual 57
8 Unplug the column SmartID key from the lower USB port.
9 Using the Intuvo torque driver, remove the two compression bolts that seal
the column's click and run connectors to the bus and store for later use.
10 Remove and store the column for later use in accordance with the column
manufacturer's recommendations.
11 Replace the gasket with a new gasket rated for the maximum column
temperature expected with your method. (See “To Replace an Intuvo 9000
GC Gasket” on page 59.)
Figure 12. 9000 GC column and related parts
SmartID key
Column clamps
Retainer ring
Compression
bolts
Click and run
connectors
