5 Maintenance
Nebulizer
Agilent 6475 Triple Quad LC/MS System User Guide 74
Parts needed:
• Replacement needed kit
To inspect the nebulizer,
1 Put on clean powder-free nitrile gloves.
2 Determine your nebulizer type.
3 Carefully insert the tip of the nebulizer into the end of the Nebulizer
Adjustment Fixture.
4 Slide the heads of the two spring loaded socket head cap screws through the
mounting holes on the body of the nebulizer.
5 Turn the nebulizer body 1/8 turn counterclockwise.
If the nebulizer is too tight or too loose, loosen or tighten the nut on the captured
screws to adjust the tension on the spring. Turn clockwise to tighten,
counterclockwise to loosen.
6 Gently push the 40 x Magnifier into the end horizontal position of the
Nebulizer Adjustment Fixture. Align the tapered tip of the magnifier to the tip
of the nebulizer needle.
7 Push the LED Flashlight into the Nebulizer Adjustment Fixture. No tool is
needed.
8 Turn on the LED Flashlight. The on/off switch is at the end of the flashlight.
Do not hit or touch the end of the nebulizer or you can damage the needle.
9 Gently push the LED Flashlight into the end horizontal position of the
Nebulizer Adjustment Fixture.
10 Push the 40 x Magnifier into the Nebulizer Adjustment Fixture. No tool is
needed. Align the tapered tip of the magnifier to the tip of the nebulizer needle.
11 Turn on the LED Flashlight. The on/off switch is at the end of the flashlight.
Do not hit or touch the end of the nebulizer or you can damage the needle.
