40 Operating Guide
4 Keypad Operation
The Status Key
[Status] Toggles between setpoint/actual values for
most commonly reviewed parameters and
displays “ready,” “not ready,” and “fault”
information.
When the Not Ready status light is blinking, a
fault has occurred. Press [Status] to see which
parameters are not ready and what fault has
occurred.
The order in which items appear in the
scrolling display window for [Status] can be
modified. You may, for example, want to
display the things you most frequently check
in the top three lines so that you do not need
to scroll to see them. To change the order of
the Status display:
1 Press [Config] [Status].
2 Scroll to the setpoint you want to appear
first and press [Enter]. This setpoint will
now appear at the top of the list.
3 Scroll to the setpoint you want to appear
second and press [Enter]. This setpoint will
now be the second item on the list.
4 Continue as above until the list is in the
order you require.
