Operating the 7693A Automatic Sampler 5
Operating Guide 59
To Configure Solvent/Waste Vials
Press [Config] [Front Injector] or [Config] [Back Injector] on the
GC keypad to display the front or back injector configuration
parameters.
Wash Mode Bottles — This is only displayed when the injector
has a transfer turret installed. The turret solvent bottle
positions are selected using the [Mode/Type] key:
6-A and 4-B Washes — Uses all 6 solvent A bottles if injector
uses solvent A washes. Uses all 4 solvent B bottles if
injector uses solvent B washes. The injector alternates
between all bottles.
2-A and 2-B Washes — Uses solvent bottles A and A2 if
injector uses solvent A washes and solvent bottles B and
B2 if injector uses solvent B washes. The injector
alternates between all bottles.
1-A and 1-B Washes — Uses solvent bottle A if injector uses
solvent A washes and solvent bottle B if injector uses
solvent B washes.
The injector always uses both WA waste bottles if a
solvent A wash is used and both WB waste bottles if a
solvent B wash is used.
Syringe size — Enter a syringe size between 0.5 and 500 µL.
CONFIGURE FRONT INJECTOR
Wash Mode Bottles 1 A, 1 B
Syringe Size 10.0
The GC assumes the syringe volume represents full plunger stroke. If the
maximum volume marked on the syringe barrel is halfway up the barrel,
you will need to enter double that volume (the label in this case is half of
the full plunger stroke).
