Operating the 7683 Automatic Sampler 6
Operating Guide 77
To Load Vials in the 7683 ALS Turret
1 Load waste and solvent bottles in the appropriate
positions. Be sure that there is a waste bottle in each
position of the turret, regardless of which ones are
configured in the method.
2 Load the sample vial(s) in the appropriate locations
(Positions 1 through 8 for an 8- sample turret and Position
1 for a 1- sample turret when not using a tray).
To Load Vials in the 7683 ALS Sampler Tray
1 Install the 1- sample turret, if not already installed. (See
“To Change the 7683 ALS Turret”.)
2 Place up to 100 sample vials in the four tray quadrants
according to the programmed sequence. Do not place a
sample in the turret.
Tray loading for a sequence that uses tray positions
6 through 21 is shown below.
3 Review the “7683 ALS Prerun Checklist” before starting a
run.
Last vial in
position 21
First vial in
position 6
