62 Operating Guide
5 Operating the 7693A Automatic Sampler
6
If the injector cable is disconnected, reconnect it to the
injector cable port.
7 Position the injector on the desired mounting post and
inlet cover support foot.
Check your work
The injector must be vertical and stable.
If the injector will not sit upright on the GC, check that the
plumbing and cabling under the inlet cover are properly
routed in their channels. If a tray is installed, also verify
that the front injector cable is routed correctly through the
GC mounting bracket support as shown in Figure 8.
If using a tray, you should calibrate the system. Refer to the
7693A ALS Installation, Operation, and Maintenance manual.
Impact on your data system
After moving the injector, an Agilent data system will detect
the configuration change and may prompt you to verify the
loaded method.
Verify the data system will use the new injection source for
any runs.
