172 Chapter3
Softkey Menus
Menu Trees
Figure 3-8 CONFIG Key Menu Tree
* Changes to STORE HPIB ADR if pressed.
† Not available for an 8560E/EC with Option 002 installed in it and
non-functional for instruments with Option 327.
‡
Both E-series and EC-seriesinstruments appear as E-seriesin the instrument
display when the DATECODE&OPTIONS key is pressed. EC-series
instruments also appear as Option 007 instruments (Option 007 is the FADC
option, which is standard in EC-series instruments).
