Agilent Technologies 8560E - MKMIN Marker to Minimum; Figure 7-170 MKMIN Syntax

522 Chapter7
Language Reference
MKMIN Marker to Minimum
MKMIN Marker to Minimum
Syntax
Figure 7-170 MKMIN Syntax
Description
The MKMIN command places an active marker on the minimum signal
detected on a trace.
Example
10 OUTPUT 718;"IP;SNGLS;"
20 INPUT "ENTER IN THE START FREQUENCY, IN MHZ",Start_freq
30 INPUT "ENTER IN THE STOP FREQUENCY, IN MHZ",Stop_freq
40 OUTPUT 718;"FA ";Start_freq;"MHZ"
50 OUTPUT 718;"FB ";Stop_freq;"MHZ"
60 OUTPUT 718;"TS;MKPK HI;MKD;MKMIN;MKF?;"
70 ENTER 718;Delta_freq
80 OUTPUT 718;"MKA?;"
90 ENTER 718;Delta_amp
100 PRINT "DIFFERENCE IN FREQUENCY IS ",Delta_freq,"HZ"
110 PRINT "DIFFERENCE IN AMPLITUDE IS",Delta_amp,"DB"
120 END
