Chapter 5 291
Programming
Setup Procedure for Remote Operation
Setup Procedure for Remote Operation
The following procedure describes how to connect your equipment for
remote operation of the 8560 E-Series or EC-Series spectrum analyzers.
NOTE Refer to the Chapter 1 for more information on installing, configuring,
and addressing the system.
1. Connect computer, spectrum analyzer system, and other peripherals
with GPIB cables. The Agilent 85620A mass memory module can be
attached for downloadable programming (DLP) capabilities. Turn off
the analyzer before installing or removing any option module.
2. After the GPIB cables are installed, reset all instruments connected
to the bus. (If you are not sure how to reset a device, switch off the
line power to the device, and then switch the line power back on to
reset it.)
3. Check the GPIB address of the spectrum analyzer by pressing
CONFIG, then ANALYZER ADDRESS. Note that examples in this
section, use GPIB address 18.
