Chapter 3 175
Softkey Menus
Menu Trees
Figure 3-14 MEAS/USER Key Menu Tree
* Spectrum analyzers with firmware revisions ≤930809 have fewer power and
adjacent channel power (ACP) functions.
† See the following figure for ACP setup menus.
‡ The SPAN softkey is displayed if the markers are not active.
§ Present only when this menu is accessed from the occupied power menu.
