Programmer’s Guide 10-3
Menu Map with SCPI Commands
Entering Frequency, Power, and Other Numeric Values
Entry of frequency, power, and other numeric values requires a choice of
measurement unit. All entries of this type follow the same sequence:
Enter the number then choose the appropriate unit, or press Enter for
default units.
Menu Map Tables and Instrument Types
The instrument displays menu choices based on the instrument type and
the active measurement channel configuration. In the tables of softkey
menu choices that follow, the instrument type is shown in the table title,
and the channel configuration is shown in the table body. See Figure
10-1, below.
Figure 10-1 Example Menu Map Table
Table 10-8 CAL Functions, 8712ES/8714ES
KEYSTROKES SCPI COMMAND
CAL (Reflection) (hardkey entry)
Default 1-Port SENS[1|2]:CORR:CSET DEF; *WAI
Default 2-Port SENS[1|2]:CORR:CLASS DEF2; *WAI
User 1-Port SENS[1|2]:CORR:CLASS DEF1; *WAI
SENS[1|2]:CORR:CSET DEF; *WAI
SCPI command
Hardkey
Channel configuration
Applicable models
Softkey
To Next Page
