10-10 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-2 BEGIN Functions, 8712ET and 8714ET (1 of 3)
1. The active measurement channel configuration determines the order of appearance
and the content of the softkey menus.
2. Option 100 (SRL and Fault Location) only.
KEYSTROKES SCPI COMMAND
BEGIN
1
(hardkey entry)
Amplifier (menu selection only)
Transmissn CONF 'AMPL:TRAN';*WAI
Reflection CONF 'AMPL:REFL';*WAI
Power CONF 'AMPL:POW';*WAI
Filter (menu selection only)
Transmissn CONF ‘FILT:TRAN’;*WAI
Reflection CONF ‘FILT:REFL’;*WAI
Broadband Passive (menu selection only)
Transmissn CONF ‘BBAN:TRAN’;*WAI
Reflection CONF ‘BBAN:REFL’;*WAI
Mixer (menu selection only)
Conversion Loss CONF ‘MIX:CLOS’;*WAI
Reflection CONF ‘MIX:REFL’;*WAI
Cable
2
(menu selection only)
Transmissn CONF[1|2] ‘CABL:TRAN’;*WAI
Reflection CONF[1|2] ‘CABL:REFL’;*WAI
Fault Location CONF[1|2] ‘CABL:FAULT’;*WAI
Start Distance SENS[1|2]:DIST:STAR <num>[FEET|MET];*WAI
Stop Distance SENS[1|2]:DIST:STOP <num>[FEET|MET];*WAI
