10-14 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-3 BEGIN Functions, 8712ES and 8714ES (2 of 3)
1. Option 100 (SRL and Fault Location) only.
KEYSTROKES SCPI COMMAND
BEGIN,(continue)
Cable
1
(continue)
Transmissn CONF[1|2] ‘CABL:TRAN’;*WAI
Reflection CONF[1|2] ‘CABL:REFL’;*WAI
Fault Location CONF[1|2] ‘CABL:FAULT’;*WAI
Start Distance SENS[1|2]:DIST:STAR <num>[FEET|MET];*WAI
Stop Distance SENS[1|2]:DIST:STOP <num>[FEET|MET];*WAI
Feet SENS:DIST:UNIT FEET
Meters SENS:DIST:UNIT MET
Low Pass SENS:FREQ:MODE LOWP;*WAI
Band Pass SENS:FREQ:MODE CENT;*WAI
Center Frequency SENS[1|2]:FREQ:CENT <value>;*WAI
SRL CONF[1|2] ‘CABL:SRL’;*WAI
Start Freq DISP:ANN:FREQ[1|2]:MODE SSTOP
(enter value
and units)
SENS[1|2]:FREQ:STAR <num>[MHZ|KHZ|HZ];*WAI
Stop Freq DISP:ANN:FREQ[1|2]:MODE SSTOP
(enter value
and units)
SENS[1|2]:FREQ:STOP <num>[MHZ|KHZ|HZ];*WAI
