10-16 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-4 CAL Functions, 8712ES and 8714ES (1 of 3)
1. Pressing this key begins a guided calibration procedure using three standards.
When the calibration is complete, the command *WAI;:SENS[1|2]:CORR:COLL:
SAVE;*WAI is executed. The order of appearance and the content of the softkey
menus depend on the measurement channel 1 and measurement channel 2 configu-
rations.
2. Pressing this softkey begins a guided 2-port calibration procedure, using seven
standards. When the calibration is complete, the command *WAI;:SENS[1|2]
:CORR:COLL:SAVE;*WAI is executed. The order of appearance and the content of
the softkey menus depend on the measurement channel 1 and measurement chan-
nel 2 configurations.
KEYSTROKES SCPI COMMAND
CAL, (Reflection) (hardkey entry)
Default 1-Port SENS[1|2]:CORR:CSET DEF; *WAI
Default 2-Port SENS[1|2]:CORR:CLASS DEF2; *WAI
User 1-Port SENS[1|2]:CORR:CLASS DEF1; *WAI
Default 1-Port SENS[1|2]:CORR:CSET DEF; *WAI
User 1-Port SENS[1|2]:CORR:COLL:IST OFF;METH REFL3;
*WAI
Measure Standard
1
SENS[1|2]:CORR:COLL STAN[1|2|3];*WAI
User 2-Port SENS[1|2]:CORR:CLASS DEF2; *WAI
Default 2-Port SENS[1|2]:CORR:CLASS DEF2; *WAI
User 2-Port SENS[1|2]:CORR:COLL:IST OFF;METH TWOP;
*WAI
Measure Standard
2
SENS[1|2]:CORR:COLL STAN[1|2|...|7];*WAI
Isolation on OFF SENS:CORR:ISOL ON; *WAI
Normalize on OFF TRAC CH[1|2]SMEM,CH[1|2]SDATA;:CALC[1|2]:
MATH (IMPL/CH[1|2]SMEM);:DISP:WIND[1|2]:
TRAC[1|2] ON;TRAC[1|2] OFF
More Cal (see Table 10-11) (menu selection only)
