10-26 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-11 CAL, More CAL Functions, 8712ET/ES and 8714ET/ES (1 of 4)
1. The port number in each command is the port selected from the screen using the up
and down keys.
2. The instrument system impedance determines the set of valid connector choices in
this menu. Connectors with a characteristic impedance other than the instrument
system impedance are dimmed on the screen.
3. This Key is active if port extensions are on.
4. For 8712ES and 8714ES analyzers.
5. For 8712ET and 8714ET analyzers.
KEYSTROKES SCPI COMMAND
CAL, More Cal
1, 2
(menu selection only)
Port Extensions (menu selection only)
Port Ext’s ON off SENS[1|2]:CORR:EXT [ON|OFF]
Port 1 Extension
3, 4
(Refl Port Extensions)
3, 5
SENS[1|2]:CORR:EXT:REFL:TIME <num> s
Port 2 Extension
3, 4
(Trans Port Extensions)
3, 5
SENS[1|2]:CORR:EXT:TRAN:TIME <num> s
Velocity Factor SENS[1|2]:CORR:RVEL:COAX <num>
Smith Chart Z0 SENS[1|2]:CORR:IMP:INP:MAGN <num> OHM
System Z0 SENS[1|2]:CORR:IMP:INP:MAGN:SEL
Z0_[50|75]
50 Ω SENS[1|2]:CORR:EXT:REFL:TIME <num> s
75 Ω SENS[1|2]:CORR:EXT:REFL:TIME <num> s
Cal Kit (menu selection only)
Type-N(f) (Default) SENS:CORR:COLL:CKIT:PORT[1|2]
‘COAX,7MM,TYPE-N,75,FEMALE’
Type-N(m) SENS:CORR:COLL:CKIT:PORT[1|2]
‘COAX,7MM,TYPE-N,75,MALE’
To Next Page
