Agilent Technologies 8712ET - Page 155

Programmer’s Guide 10-27
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-10 CAL, More CAL Functions, 8712ET/ES and 8714ET/ES (2 of 4)
1. The port number in each command is the port selected from the screen using the up
and down keys.
KEYSTROKES SCPI COMMAND
CAL, More Cal (continued) (menu selection only)
Cal Kit (continued) (menu selection only)
3.5 mm SENS:CORR:COLL:CKIT:PORT1
‘COAX,3.5MM,APC-3.5,50,IMPLIED’
Type-F SENS:CORR:COLL:CKIT:PORT1
‘COAX,7MM,TYPE-F,75,IMPLIED’
APC-7 SENS:CORR:COLL:CKIT:PORT1
‘COAX,7MM,APC-7,50,IMPLIED’
7-16 SENS:CORR:COLL:CKIT:PORT1
‘COAX,7MM,TYPE-7-16,50,IMPLIED’
User Cal
Kit A
1
SENS:CORR:COLL:CKIT:PORT[1|2]
‘USER,IMPLIED,IMPLIED,IMPLIED,IMPLIED’
User Cal
Kit B
1
SENS:CORR:COLL:CKIT:PORT[1|2]
‘USER2,IMPLIED,IMPLIED,IMPLIED,IMPLIED’
User Cal
Kit C
1
SENS:CORR:COLL:CKIT:PORT[1|2]
‘USER3,IMPLIED,IMPLIED,IMPLIED,IMPLIED’
User Cal
Kit D
1
SENS:CORR:COLL:CKIT:PORT[1|2]
‘USER4,IMPLIED,IMPLIED,IMPLIED,IMPLIED’
User Cal
Kit E
1
SENS:CORR:COLL:CKIT:PORT[1|2]
‘USER5,IMPLIED,IMPLIED,IMPLIED,IMPLIED’
User Cal
Kit F
1
SENS:CORR:COLL:CKIT:PORT[1|2]
‘USER6,IMPLIED,IMPLIED,IMPLIED,IMPLIED’
User Cal
Kit G
1
SENS:CORR:COLL:CKIT:PORT[1|2]
‘USER7,IMPLIED,IMPLIED,IMPLIED,IMPLIED’
