Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-10 CAL, Cal Check Functions, 8712ET/ES and 8714ET/ES
1. Only those calibration checks valid for the current measurement type are active,
other choices are dimmed. For example, Transmission Tracking is not valid for reflec-
tion measurements.
KEYSTROKES SCPI COMMAND
CAL, Cal Check (menu selection only)
Do Cal Check SENS1:CORR:COLL:IST OFF;METH VERIFY;*WAI
Measure Standard
1
SENS[1|2]:CORR:COLL:VER:REFL
STAN[1|2|3];*WAI;
View Cal Check
1
(menu selection only)
Directivity DIAG:MDIS[1|2]:CORR C_DIRECT; *WAI
Source Match DIAG:MDIS[1|2]:CORR C_SRCMATCH; *WAI
Reflection Tracking DIAG:MDIS[1|2]:CORR C_RTRACKING; *WAI
Load Match DIAG:MDIS[1|2]:CORR C_LDMATCH; *WAI
Transmissn
Tracking
DIAG:MDIS[1|2]:CORR C_TTRACKING; *WAI
Isolation DIAG:MDIS[1|2]:CORR C_ISOLATION; *WAI
Restore Meas DIAG:MDIS[1|2]:REST; *WAI
