Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-8 Functions, 8712ET/ES and 8714ET/ES
1. Pressing this key begins a guided calibration procedure using three standards.
When the calibration is complete, the command
*WAI;:SENS[1|2]:CORR:COLL:SAVE;*WAI is executed.
KEYSTROKES SCPI COMMAND
CAL, (SRL)
Default Cal SENS[1|2]:CORR:CSET DEF; *WAI
Full Band Cal SENS[1|2]:CORR:EXT [ON|OFF]
Measure Standard
1
SENS[1|2]:CORR:COLL STAN[1|2|3];*WAI
Connector Model (menu selection only)
Measure Connector (menu selection only)
Measure SENS[1|2]:CORR:MODEL:CONN
Connector Length SENS[1|2]:CORR:LENG:CONN <num>
Connector C SENS[1|2]:CORR:CAP:CONN <num>
Z cutoff Frequency SENS:FREQ:ZST <num>
Auto Z ON off SENS[1|2]:FUNC:SRL:MODE [MANUAL|AUTO]
Manual Z SENS[1|2]:FUNC:SRL:IMP <num>
Connector Fault (sets instrument to connector fault display)
Cal Check
(see Table 10-10 on page 10-25)
(menu selection only)
More Cal
(see Table 10-11 on page 10-26)
(menu selection only)
