10-22 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-7 CAL, Functions, 8712ET/ES and 8714ET/ES
1. Pressing this key begins a guided calibration procedure using three standards.
When the calibration is complete, the command *WAI;:SENS[1|2]:CORR:COLL:
SAVE;*WAI is executed. The order of appearance and the content of the softkey
menus depend on the measurement channel 1 and measurement channel 2 configu-
ration.
KEYSTROKES SCPI COMMAND
CAL, (Fault Location)
Default Cal SENS[1|2]:CORR:CSET DEF; *WAI
Full Band Cal SENS[1|2]:CORR:EXT [ON|OFF]
Measure Standard
1
SENS[1|2]:CORR:COLL STAN[1|2|3];*WAI
Velocity Factor SENS[1|2]:CORR:RVEL:COAX <value>
Cable Loss SENS[1|2]:CORR:LOSS:COAX <value>
Calibrate Cable (menu selection only)
Specify Length SENS[1|2]:CORR:LENG:COAX <value>; *WAI
Measure Cable SENS[1|2]:CORR:RVEL; *WAI
Multi Peak (menu selection only)
Multi Peak Corr on OFF SENS[1|2]:CORR:PEAK:COAX ON
Multi Peak Threshold SENS[1|2]:CORR:THRESHOLD:COAX -10.00
Connector Values (menu selection only)
Connector Length SENS[1|2]:CORR:LENG:CONN <value>
Connector C SENS1:CORR:CAP:CONN <value>
More Cal
(see Table 10-11 on page 10-26)
(menu selection only)
