Programmer’s Guide 10-37
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-14 FREQ Functions, 8712ET/ES and 8714ET/ES
1. The active measurement channel configuration determines the order of appearance
and the content of the softkey menus.
2. Available for fault location measurements only.
KEYSTROKES SCPI COMMAND
FREQ
1
(hardkey entry)
Start DISP:ANN:FREQ1:MODE SSTOP
SENS[1|2]:FREQ:STAR <value> HZ;*WAI
Stop DISP:ANN:FREQ1:MODE SSTOP
SENS[1|2]:FREQ:STOP <value> HZ;*WAI
Center DISP:ANN:FREQ1:MODE CSPAN
SENS[1|2]:FREQ:CENT <value> HZ;*WAI
Span DISP:ANN:FREQ1:MODE CSPAN
SENS[1|2]:FREQ:SPAN <value> HZ;*WAI
CW DISP:ANN:FREQ1:MODE CW;:
SENS[1|2]:FREQ:SPAN 0 HZ;;*WAI
SENS[1|2]:FREQ:CENT 300000 HZ;*WAI
Fault Loc Frequency
2
(menu selection only)
Low Pass SENS:FREQ:MODE LOWP; *WAI
Band Pass SENS:FREQ:MODE CENT
Band Pass Max Span SENS[1|2]:FREQ:SPAN:MAX <value>
Displ Freq Resolution CALC[1|2]:FORM IMAG
MHz DISP:ANN:FREQ:RES MHZ
kHz DISP:ANN:FREQ:RES KHZ
Hz DISP:ANN:FREQ:RES HZ
To Next Page
