10-36 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-13 FORMAT Functions, 8712ET/ES and 8714ET/ES
1. The active measurement channel configuration determines the order of appearance
and the content of the softkey menus.
2. This menu lists the units available for selection using Log Mag or Lin Mag format
only.
KEYSTROKES SCPI COMMAND
FORMAT
1
(hardkey entry)
Log Mag CALC[1|2]:FORM MLOG
Lin Mag CALC[1|2]:FORM MLIN
SWR CALC[1|2]:FORM SWR
Delay CALC[1|2]:FORM GDEL
Phase CALC[1|2]:FORM PHAS
Smith Chart CALC[1|2]:FORM SMIT
Polar CALC[1|2]:FORM POL
More Format (menu selection only)
Real CALC[1|2]:FORM REAL
Imaginary CALC[1|2]:FORM IMAG
Impedance Magnitude CALC[1|2]:FORM MIMP
Mag Units
2
(menu selection only)
dBW CALC[1|2]:FORM:UNIT:MLOG DBW
dBm CALC[1|2]:FORM:UNIT:MLOG DBMW
dBuW CALC[1|2]:FORM:UNIT:MLOG DBUW
dBV CALC[1|2]:FORM:UNIT:MLOG DBV
dBmV CALC[1|2]:FORM:UNIT:MLOG DBMV
dBuV CALC[1|2]:FORM:UNIT:MLOG DBUV
