Programmer’s Guide 10-35
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-12 DISPLAY Functions, 8712ET/ES and 8714ET/ES (5 of 5)
1. The active measurement channel configuration determines the order of appearance
and the content of the softkey menus.
2. First choose an item (Background=1, User Graphics Pen 1=2 through User Graph-
ics Pen 7=8, Inactive Text=9, Warning Text=10, Graticule=11, Trace 1=12, Mem
1=13, Trace 2=14, Mem 2=15, Text=16) with Select Item, then choose a color item to
change, and enter a new value. The softkey menu displays Enter and Cancel. Press
Enter to save your changes.
3. COL[1|2|...|16] selects one of the 16 items listed in Footnote 2, above. HSL
h,s,l sets the hue, saturation and luminance values, respectively.
KEYSTROKES SCPI COMMAND
DISPLAY
1
, Color Options, (continued)
Custom Colors
2
(menu selection only)
Select Item (select item, 1-16)
Hue DISP:CMAP:COL[1|2|...|16]:HSL h,s,l
3
Saturation
DISP:CMAP:COL[1|2|...|16]:HSL h,s,l
3
Luminance
DISP:CMAP:COL[1|2|...|16]:HSL h,s,l
3
Int Disp Intensity DISP:CMAP:COL16:GREY [0-1.00]
Annotation Options (menu selection only)
Meas Annot ON off DISP:ANN:CHAN[1|2] [ON|OFF]
Freq Annot ON off DISP:ANN:FREQ[1|2] [ON|OFF]
Mkr Annot ON off DISP:ANN:MARK[1|2] [ON|OFF]
Mkr Number ON off DISP:ANN:MARK[1|2]:NUMB [ON|OFF]
Y-Axis Lbl ON off DISP:ANN:YAX [ON|OFF]
Y-Axis Lbl rel ABS DISP:ANN:YAX:MODE [REL|ABS]
Graticule ON off DISP:WIND1:TRAC:GRAT:GRID [ON|OFF]
