10-34 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-12 DISPLAY Functions, 8712ET/ES and 8714ET/ES (4 of 5)
1. The active measurement channel configuration determines the order of appearance
and the content of the softkey menus.
KEYSTROKES SCPI COMMAND
DISPLAY
1
, (continued)
Split Disp FULL split DISP:FORM [ULOW|SING]
Expand ON off DISP:FORM:EXPAND [ON|OFF]
Title and Clock DISP:ANN:TITL ON
Enter Line 1 (enter text,
press Enter)
DISP:ANN:TITL[1|2]:DATA, ‘text’
Enter Line 2 (enter text,
press Enter)
DISP:ANN:TITL[1|2]:DATA, ‘text’
Show Clock on Line 1 DISP:ANN:CLOC:MODE LINE1
Show Clock on Line 2 DISP:ANN:CLOC:MODE LINE2
Clock Off DISP:ANN:CLOC:MODE OFF
Title+Clk ON off DISP:ANN:TITL [ON|OFF]
Color Options (menu selection only)
Factory default DISP:CMAP:SCHEME DEFAULT
Default 2 DISP:CMAP:SCHEME DEFAULT2
Grey Scale DISP:CMAP:SCHEME GREY
Inverse Video DISP:CMAP:SCHEME INV
To Next Page
